D-LINK · NOD-DGS-3130-54TS/SI

Switch D-Link DGS-3130-54TS/SI, 54-Port Gigabit SFP L3 Stackable Managed Switch, 48 x 10/100/1000BASE-T ports

Name: Switch D-Link DGS-3130-54TS/SI, 54-Port Gigabit SFP L3 Stackable Managed Switch, 48 x 10/100/1000BASE-T ports
Brand: D-LINK
SKU: NOD-DGS-3130-54TS/SI
Price: 13540 RON
Availability: BackOrder

Switch D-Link DGS-3130-54TS/SI, 54-Port Gigabit SFP L3 Stackable Managed Switch, 48 x 10/100/1000BASE-T ports, 2 x 10GBASE-T and 4 x 10G SFP+ ports, Layer 3, 80 Gbps.

11.190 lei

prețuri fără TVA · 13.540 lei cu TVA

La comandă·5–7 zile

Produs disponibil doar cu cont de firmă verificat. Creează cont B2B →

Cantitate

Preț de volum de la 5 buc. — cere ofertă

Total 1 buc.11.190 lei

D-LINK · NetworkingDoar pentru firme (B2B)

Switch D-Link DGS-3130-54TS/SI, 54-Port Gigabit SFP L3 Stackable Managed Switch, 48 x 10/100/1000BASE-T ports

SKU: NOD-DGS-3130-54TS/SI

10G support: Yes
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Access Control List (ACL): Yes
Access Control List (ACL) egress: 512
Access Control List (ACL) ingress: 2048

Prețuri de volum

Pentru 5+ bucăți primești preț negociat — trimite o cerere de ofertă din coș.

11.190 leiprețuri fără TVA

La comandă·5–7 zile

Cere ofertă pentru volum

Acest produs se poate comanda doar cu cont de firmă verificat. Creează cont B2B →

Retur gratuit 30 de zileFactură fiscală automatăGaranție de producător

BrandD-LINK

Cod produsNOD-DGS-3130-54TS/SI

CategorieNetworking

10G supportYes

AC input frequency50 - 60 Hz

AC input voltage100 - 240 V

Access Control List (ACL)Yes

Access Control List (ACL) egress512

Access Control List (ACL) ingress2048

ARP inspectionYes

AuthenticationGuest VLAN, MAC-based authentication, Port-based authentication

Basic switching RJ-45 Ethernet ports quantity48

Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)

BPDU filtering/protectionYes

Broadcast storm controlYes

CertificationFCC A, CE A, VCCI A, IC, RCM, BSMI, CCC

Copper ethernet cabling technology10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T

Depth290 mm

DHCP featuresDHCP server, DHCP snooping, DHCP relay, DHCP client

DoS attack preventionYes

Fiber optic connectorSFP

Flow control supportYes

Forwarding rate161 Mpps

GARP VLAN Registration Protocol (GVRP)Yes

Harmonized System (HS) code85176990

Head-of-line (HOL) blockingYes

Heat dissipation172.72 BTU/h

Height44 mm

I/O ports2 x 10GBASE-T

IGMP snoopingYes

Installed SFP modules quantity0

Installed SFP+ modules quantity0

Jumbo frames supportYes

LAN-Port-TypeGigabit

LED indicatorsYes

Link aggregationYes

Loop protectionYes

MAC address table16384 entries

ManagementDa

Master (outer) cases per pallet (air)48 pc(s)

Master (outer) cases per pallet (sea)48 pc(s)

Mean time between failures (MTBF)478258 h

Montare in RackDa

Multicast featuresControllable multicast

Multicast supportYes

Noise level51.9 dB

Number of fans2 fan(s)

Number of queues8

Number of VLANs4000

Operating relative humidity (H-H)10 - 90%

Operating temperature (T-T)0 - 50 °C

Package depth506 mm

Package height70 mm

Package weight4.83 kg

Package width427 mm

Packet buffer memory4 MB

Pallet gross length110 cm

Pallet gross weight (air)522.6 kg

Pallet gross weight (sea)522.6 kg

Pallet gross width120 cm

Pallet height (air)197.5 cm

Pallet height (sea)197.5 cm

Password protectionYes

Physical stacking (units)9

PoENu

Port mirroringYes

Porturi RJ 4528+

Porturi SFP3-4

Power connectorAC-in jack

Power consumption (max)50.62 W

Power over Ethernet (PoE)No

Product colourBlack, Grey

Products per pallet (air)96 pc(s)

Products per pallet (sea)96 pc(s)

Products per shipping (inner) case2 pc(s)

Quality of Service (QoS) supportYes

Queue scheduling algorithmsSP, WRR+SP, Weighted Round Robin (WRR)

Rack mountingYes

Redundant power supply (RPS) supportYes

Root protectionYes

Routing protocolsRIP

SafetyCB, cUL, BSMI, CCC

Security algorithmsSNMP, SNMPv3, SSH-2, SSL/TLS

sFlowYes

SFP module slots quantity4

SFP+ module slots quantity4

Shipping (inner) case gross weight10.5 kg

Shipping (inner) case height46 cm

Shipping (inner) case length52.4 cm

Shipping (inner) case net weight9.66 kg

Shipping (inner) case width19.8 cm

Spanning tree protocolYes

SSH/SSL supportYes

StackableYes

Storage relative humidity (H-H)5 - 90%

Storage temperature (T-T)-40 - 70 °C

Switch layerL3

Switch typeManaged

Switching capacity216 Gbit/s

System event logYes

TelnetYes

USB 2.0 ports quantity1

Virtual LAN featuresPrivate VLAN, Voice VLAN, Tagged VLAN, MAC address-based VLAN, Port-based VLAN

Virtual Router Redundancy Protocol (VRRP)Yes

Virtual stacking (units)32

Viteza transfer10G+

VLAN supportYes

Web-based managementYes

Weight3.72 kg

Width440 mm

Specificații

Brand	D-LINK
Cod produs	NOD-DGS-3130-54TS/SI
Categorie	Networking
Garanție	Se confirmă la ofertare
Livrare	5–7 zile
10G support	Yes
AC input frequency	50 - 60 Hz
AC input voltage	100 - 240 V
Access Control List (ACL)	Yes
Access Control List (ACL) egress	512
Access Control List (ACL) ingress	2048
ARP inspection	Yes
Authentication	Guest VLAN, MAC-based authentication, Port-based authentication
Basic switching RJ-45 Ethernet ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
BPDU filtering/protection	Yes
Broadcast storm control	Yes
Certification	FCC A, CE A, VCCI A, IC, RCM, BSMI, CCC
Copper ethernet cabling technology	10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T
Depth	290 mm
DHCP features	DHCP server, DHCP snooping, DHCP relay, DHCP client
DoS attack prevention	Yes
Fiber optic connector	SFP
Flow control support	Yes
Forwarding rate	161 Mpps
GARP VLAN Registration Protocol (GVRP)	Yes
Harmonized System (HS) code	85176990
Head-of-line (HOL) blocking	Yes
Heat dissipation	172.72 BTU/h
Height	44 mm
I/O ports	2 x 10GBASE-T
IGMP snooping	Yes
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
Jumbo frames support	Yes
LAN-Port-Type	Gigabit
LED indicators	Yes
Link aggregation	Yes
Loop protection	Yes
MAC address table	16384 entries
Management	Da
Master (outer) cases per pallet (air)	48 pc(s)
Master (outer) cases per pallet (sea)	48 pc(s)
Mean time between failures (MTBF)	478258 h
Montare in Rack	Da
Multicast features	Controllable multicast
Multicast support	Yes
Noise level	51.9 dB
Number of fans	2 fan(s)
Number of queues	8
Number of VLANs	4000
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 50 °C
Package depth	506 mm
Package height	70 mm
Package weight	4.83 kg
Package width	427 mm
Packet buffer memory	4 MB
Pallet gross length	110 cm
Pallet gross weight (air)	522.6 kg
Pallet gross weight (sea)	522.6 kg
Pallet gross width	120 cm
Pallet height (air)	197.5 cm
Pallet height (sea)	197.5 cm
Password protection	Yes
Physical stacking (units)	9
PoE	Nu
Port mirroring	Yes
Porturi RJ 45	28+
Porturi SFP	3-4
Power connector	AC-in jack
Power consumption (max)	50.62 W
Power over Ethernet (PoE)	No
Product colour	Black, Grey
Products per pallet (air)	96 pc(s)
Products per pallet (sea)	96 pc(s)
Products per shipping (inner) case	2 pc(s)
Quality of Service (QoS) support	Yes
Queue scheduling algorithms	SP, WRR+SP, Weighted Round Robin (WRR)
Rack mounting	Yes
Redundant power supply (RPS) support	Yes
Root protection	Yes
Routing protocols	RIP
Safety	CB, cUL, BSMI, CCC
Security algorithms	SNMP, SNMPv3, SSH-2, SSL/TLS
sFlow	Yes
SFP module slots quantity	4
SFP+ module slots quantity	4
Shipping (inner) case gross weight	10.5 kg
Shipping (inner) case height	46 cm
Shipping (inner) case length	52.4 cm
Shipping (inner) case net weight	9.66 kg
Shipping (inner) case width	19.8 cm
Spanning tree protocol	Yes
SSH/SSL support	Yes
Stackable	Yes
Storage relative humidity (H-H)	5 - 90%
Storage temperature (T-T)	-40 - 70 °C
Switch layer	L3
Switch type	Managed
Switching capacity	216 Gbit/s
System event log	Yes
Telnet	Yes
USB 2.0 ports quantity	1
Virtual LAN features	Private VLAN, Voice VLAN, Tagged VLAN, MAC address-based VLAN, Port-based VLAN
Virtual Router Redundancy Protocol (VRRP)	Yes
Virtual stacking (units)	32
Viteza transfer	10G+
VLAN support	Yes
Web-based management	Yes
Weight	3.72 kg
Width	440 mm

Configurație

Switch D-Link DGS-3130-54TS/SI, 54-Port Gigabit SFP L3 Stackable Managed Switch, 48 x 10/100/1000BASE-T ports, 2 x 10GBASE-T and 4 x 10G SFP+ ports, Layer 3, 80 Gbps.

Ai nevoie de o configurație diferită? Echipa noastră o poate personaliza — Cere ofertă.

Prezentare detaliată

Switch D-Link DGS-3130-54TS/SI, 54-Port Gigabit SFP L3 Stackable Managed Switch, 48 x 10/100/1000BASE-T ports, 2 x 10GBASE-T and 4 x 10G SFP+ ports, Layer 3, 80 Gbps.

10G support: YesAC input frequency: 50 - 60 HzAC input voltage: 100 - 240 VAccess Control List (ACL): YesAccess Control List (ACL) egress: 512Access Control List (ACL) ingress: 2048
