CHIEFTEC · NOD-BBS-500S

Sursa Chieftec BBS-500S, 80 PLUS Gold, 500 W

Name: Sursa Chieftec BBS-500S, 80 PLUS Gold, 500 W
Brand: CHIEFTEC
SKU: NOD-BBS-500S
Price: 693 RON
Availability: BackOrder

Chieftec Core BBS-500S. Total power: 500 W, AC input voltage: 100 - 240 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 24-pin ATX, SATA power cable length: 150,500 mm, Peripheral (Molex) power cable length: 150,500 mm. Purpose: PC, Power supply unit (PSU) form factor: PS/2, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Width: 140 mm, Depth: 150 mm, Height: 86 mm

573 lei

prețuri fără TVA · 693 lei cu TVA

La comandă·5–7 zile

Produs disponibil doar cu cont de firmă verificat. Creează cont B2B →

Cantitate

Preț de volum de la 5 buc. — cere ofertă

Total 1 buc.573 lei

CHIEFTEC · Laptopuri & PCDoar pentru firme (B2B)

Sursa Chieftec BBS-500S, 80 PLUS Gold, 500 W

SKU: NOD-BBS-500S

80 PLUS certification: 80 PLUS Gold
AC input frequency: 47 - 63 Hz
AC input voltage: 100 - 240 V
ATX version: 2.3
Cabling type: Non-Modular
Certificare 80 Plus: 80 PLUS Gold

Prețuri de volum

Pentru 5+ bucăți primești preț negociat — trimite o cerere de ofertă din coș.

573 leiprețuri fără TVA

La comandă·5–7 zile

Cere ofertă pentru volum

Acest produs se poate comanda doar cu cont de firmă verificat. Creează cont B2B →

Retur gratuit 30 de zileFactură fiscală automatăGaranție de producător

BrandCHIEFTEC

Cod produsNOD-BBS-500S

CategorieLaptopuri & PC

80 PLUS certification80 PLUS Gold

AC input frequency47 - 63 Hz

AC input voltage100 - 240 V

ATX version2.3

Cabling typeNon-Modular

Certificare 80 Plus80 PLUS Gold

Combined power (+12V)3.6 W

Combined power (+5Vsb)12.5 W

Combined power (-12V)3.6 W

ConectivitateNon Modular

Cooling typeActive

CPU power cable length65 cm

CPU power connector (4+4 pin)Yes

Depth150 mm

Fan diameter12 cm

Floppy disk drive connectorYes

Floppy drive power connector1

Harmonized System (HS) code84733020

Height86 mm

Iluminare RGBNu

Input current8 A

Max output current (+12V)0.3 A

Max output current (+12V1)41 A

Max output current (+3.3V)18 A

Max output current (+5V)18 A

Max output current (+5Vsb)2.5 A

Max output current (-12V)0.3 A

Motherboard power connector24-pin ATX

Number of fans1 fan(s)

Number of SATA power connectors4

Package weight2.06 kg

PCI Express power cable length50 cm

PCI Express power connectors (6+2 pin)1

Peripheral (Molex) power cable length150,500 mm

Peripheral (Molex) power connectors (4-pin)3

Power Factor Correction (PFC) typeActive

Power protection featuresOver voltage, Overload, Short circuit

Power supply unit (PSU) form factorPS/2

Product colourBlack

PSU Power500 W

PurposePC

SATA power cable length150,500 mm

Total power500 W

Weight1.65 kg

Width140 mm

Specificații

Brand	CHIEFTEC
Cod produs	NOD-BBS-500S
Categorie	Laptopuri & PC
Garanție	Se confirmă la ofertare
Livrare	5–7 zile
80 PLUS certification	80 PLUS Gold
AC input frequency	47 - 63 Hz
AC input voltage	100 - 240 V
ATX version	2.3
Cabling type	Non-Modular
Certificare 80 Plus	80 PLUS Gold
Combined power (+12V)	3.6 W
Combined power (+5Vsb)	12.5 W
Combined power (-12V)	3.6 W
Conectivitate	Non Modular
Cooling type	Active
CPU power cable length	65 cm
CPU power connector (4+4 pin)	Yes
Depth	150 mm
Fan diameter	12 cm
Floppy disk drive connector	Yes
Floppy drive power connector	1
Harmonized System (HS) code	84733020
Height	86 mm
Iluminare RGB	Nu
Input current	8 A
Max output current (+12V)	0.3 A
Max output current (+12V1)	41 A
Max output current (+3.3V)	18 A
Max output current (+5V)	18 A
Max output current (+5Vsb)	2.5 A
Max output current (-12V)	0.3 A
Motherboard power connector	24-pin ATX
Number of fans	1 fan(s)
Number of SATA power connectors	4
Package weight	2.06 kg
PCI Express power cable length	50 cm
PCI Express power connectors (6+2 pin)	1
Peripheral (Molex) power cable length	150,500 mm
Peripheral (Molex) power connectors (4-pin)	3
Power Factor Correction (PFC) type	Active
Power protection features	Over voltage, Overload, Short circuit
Power supply unit (PSU) form factor	PS/2
Product colour	Black
PSU Power	500 W
Purpose	PC
SATA power cable length	150,500 mm
Total power	500 W
Weight	1.65 kg
Width	140 mm

Configurație

Ai nevoie de o configurație diferită? Echipa noastră o poate personaliza — Cere ofertă.

Prezentare detaliată

80 PLUS certification: 80 PLUS GoldAC input frequency: 47 - 63 HzAC input voltage: 100 - 240 VATX version: 2.3Cabling type: Non-ModularCertificare 80 Plus: 80 PLUS Gold
