Placa de baza MSI B550M PRO-VDH, Socket AM4, DDR4, Micro-ATX

MSI · NOD-B550M PRO-VDH

Placa de baza MSI B550M PRO-VDH, Socket AM4, DDR4, Micro-ATX

Name: Placa de baza MSI B550M PRO-VDH, Socket AM4, DDR4, Micro-ATX
Brand: MSI
SKU: NOD-B550M PRO-VDH
Price: 557 RON
Availability: BackOrder

Placa de Baza MSI B550M PRO-VDH AM4 4x DDR4, 1x PCIE x1 2x PCIE x2, 2x M.2, 4x SATA3, 1x VGA 1x HDMI 1x DP, mATX

460 lei

prețuri fără TVA · 557 lei cu TVA

La comandă·5–7 zile

Produs disponibil doar cu cont de firmă verificat. Creează cont B2B →

Cantitate

Preț de volum de la 5 buc. — cere ofertă

Total 1 buc.460 lei

MSI · ComponenteDoar pentru firme (B2B)

Placa de baza MSI B550M PRO-VDH, Socket AM4, DDR4, Micro-ATX

SKU: NOD-B550M PRO-VDH

Bluetooth: Nu
12V power connector: Yes
ATX Power connector (24-pin): Yes
Audio output channels: 7.1 channels
Cables included: SATA
Canale audio: 7.1

Prețuri de volum

Pentru 5+ bucăți primești preț negociat — trimite o cerere de ofertă din coș.

460 leiprețuri fără TVA

La comandă·5–7 zile

Cere ofertă pentru volum

Acest produs se poate comanda doar cu cont de firmă verificat. Creează cont B2B →

Retur gratuit 30 de zileFactură fiscală automatăGaranție de producător

BrandMSI

Cod produsNOD-B550M PRO-VDH

CategorieComponente

BluetoothNu

12V power connectorYes

ATX Power connector (24-pin)Yes

Audio output channels7.1 channels

Cables includedSATA

Canale audio7.1

Chassis intrusion connectorYes

Chipset audio integratRealtek

Clear CMOS jumperYes

Compatible processor seriesAMD Ryzen 3000 Series

Component forPC

CPU fan connectorYes

Depth24.4 mm

DisplayPorts quantity1

Drivers includedYes

DVI-D ports quantity0

ECC сompatibilityECC & Non-ECC

eSATA ports quantity0

Ethernet interface typeGigabit Ethernet

Ethernet LANYes

Firewire (IEEE 1394) ports0

FormatMicro-ATX

Front panel audio connectorYes

Front panel connectorYes

GamingNu

Harmonized System (HS) code84733020

HDMIDa

HDMI ports quantity1

HDMI version2.1

Height65 mm

LAN controllerRealtek 8111HN

Maximum internal memory128 GB

Maximum number of SMP processors1

Maximum resolution4096 x 2160 pixels

Memorie maxima128 GB

Memory channelsDual-channel

Memory slots typeDIMM

Model ChipsetB550

Motherboard chipsetAMD B550

Motherboard chipset familyAMD

Motherboard form factormicro ATX

Numar sloturi memorie4

Number of chassis fan connectors3

Number of M.2 (M) slots2

Number of memory slots4

Number of Parallel ATA connectors0

Number of SATA II connectors0

Number of SATA III connectors4

Onboard-CPUNo

Parallel processing technology supportNot supported

PCI0

PCI Express x1 (Gen 3.x) slots2

PCI Express x16 (Gen 4.x) slots1

Processor manufacturerAMD

Processor socketSocket AM4

PS/2 ports quantity0

RAID levels0, 1, 10

RGB LED pin headerYes

RJ-45 LAN1

Serial port headers1

Serial-or-ParalelNo/No

Sloturi M.22

Soclu ProcesorSocket AM4

Supported memory clock speeds1866,2133,2400,2667,2800,2933,3000,3066,3200,3466,3600,3733,3866,4000,4133,4266,4400 MHz

Supported memory typesDDR4-SDRAM

Supported storage drive interfacesSATA III

Supported storage drive typesHDD & SSD

ThunderboltNu

Tip MemorieDDR4

Tip slot interfata graficaPCIe 4.0 x16

TPM connectorYes

Unbuffered memoryYes

USB 2.0 connectors2

USB 2.0 ports quantity2

USB 3.2 Gen 1 (3.1 Gen 1) connectors1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0

USB 3.2 Gen 2 (3.1 Gen 2) connectors0

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity0

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity0

USB Type CDa

VGA (D-Sub) ports quantity1

Video-ConnectionHDMI/DP

Weight1 kg

Wi-FINo

Width244 mm

WirelessNu

Specificații

Brand	MSI
Cod produs	NOD-B550M PRO-VDH
Categorie	Componente
Garanție	Se confirmă la ofertare
Livrare	5–7 zile
Bluetooth	Nu
12V power connector	Yes
ATX Power connector (24-pin)	Yes
Audio output channels	7.1 channels
Cables included	SATA
Canale audio	7.1
Chassis intrusion connector	Yes
Chipset audio integrat	Realtek
Clear CMOS jumper	Yes
Compatible processor series	AMD Ryzen 3000 Series
Component for	PC
CPU fan connector	Yes
Depth	24.4 mm
DisplayPorts quantity	1
Drivers included	Yes
DVI-D ports quantity	0
ECC сompatibility	ECC & Non-ECC
eSATA ports quantity	0
Ethernet interface type	Gigabit Ethernet
Ethernet LAN	Yes
Firewire (IEEE 1394) ports	0
Format	Micro-ATX
Front panel audio connector	Yes
Front panel connector	Yes
Gaming	Nu
Harmonized System (HS) code	84733020
HDMI	Da
HDMI ports quantity	1
HDMI version	2.1
Height	65 mm
LAN controller	Realtek 8111HN
Maximum internal memory	128 GB
Maximum number of SMP processors	1
Maximum resolution	4096 x 2160 pixels
Memorie maxima	128 GB
Memory channels	Dual-channel
Memory slots type	DIMM
Model Chipset	B550
Motherboard chipset	AMD B550
Motherboard chipset family	AMD
Motherboard form factor	micro ATX
Numar sloturi memorie	4
Number of chassis fan connectors	3
Number of M.2 (M) slots	2
Number of memory slots	4
Number of Parallel ATA connectors	0
Number of SATA II connectors	0
Number of SATA III connectors	4
Onboard-CPU	No
Parallel processing technology support	Not supported
PCI	0
PCI Express x1 (Gen 3.x) slots	2
PCI Express x16 (Gen 4.x) slots	1
Processor manufacturer	AMD
Processor socket	Socket AM4
PS/2 ports quantity	0
RAID levels	0, 1, 10
RGB LED pin header	Yes
RJ-45 LAN	1
Serial port headers	1
Serial-or-Paralel	No/No
Sloturi M.2	2
Soclu Procesor	Socket AM4
Supported memory clock speeds	1866,2133,2400,2667,2800,2933,3000,3066,3200,3466,3600,3733,3866,4000,4133,4266,4400 MHz
Supported memory types	DDR4-SDRAM
Supported storage drive interfaces	SATA III
Supported storage drive types	HDD & SSD
Thunderbolt	Nu
Tip Memorie	DDR4
Tip slot interfata grafica	PCIe 4.0 x16
TPM connector	Yes
Unbuffered memory	Yes
USB 2.0 connectors	2
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
USB Type C	Da
VGA (D-Sub) ports quantity	1
Video-Connection	HDMI/DP
Weight	1 kg
Wi-FI	No
Width	244 mm
Wireless	Nu
