Placa de baza Gigabyte X870E AORUS PRO, Socket AM5, DDR5, ATX

GIGABYTE · NOD-X870E AORUS PRO

Placa de baza Gigabyte X870E AORUS PRO, Socket AM5, DDR5, ATX

Name: Placa de baza Gigabyte X870E AORUS PRO, Socket AM5, DDR5, ATX
Brand: GIGABYTE
SKU: NOD-X870E AORUS PRO
Price: 2042 RON
Availability: BackOrder

Placa de Baza GIGABYTE X870 AORUS PRO AM5, 4x DDR5, 2x USB4 1x HDMI 1x front HDMI, 3x PCIE x16, 4x M.2, 4x SATA 6GB/s, ATX

1.688 lei

prețuri fără TVA · 2.042 lei cu TVA

La comandă·5–7 zile

Produs disponibil doar cu cont de firmă verificat. Creează cont B2B →

Cantitate

Preț de volum de la 5 buc. — cere ofertă

Total 1 buc.1.688 lei

GIGABYTE · ComponenteDoar pentru firme (B2B)

Placa de baza Gigabyte X870E AORUS PRO, Socket AM5, DDR5, ATX

SKU: NOD-X870E AORUS PRO

Bluetooth: Nu
1st M.2 highest PCI Express generation: 5.0
1st M.2 largest key size: 25110
2nd M.2 highest PCI Express generation: 5.0
2nd M.2 largest key size: 22110
3rd M.2 highest PCI Express generation: 5.0

Prețuri de volum

Pentru 5+ bucăți primești preț negociat — trimite o cerere de ofertă din coș.

1.688 leiprețuri fără TVA

La comandă·5–7 zile

Cere ofertă pentru volum

Acest produs se poate comanda doar cu cont de firmă verificat. Creează cont B2B →

Retur gratuit 30 de zileFactură fiscală automatăGaranție de producător

BrandGIGABYTE

Cod produsNOD-X870E AORUS PRO

CategorieComponente

BluetoothNu

1st M.2 highest PCI Express generation5.0

1st M.2 largest key size25110

2nd M.2 highest PCI Express generation5.0

2nd M.2 largest key size22110

3rd M.2 highest PCI Express generation5.0

3rd M.2 largest key size22110

4th M.2 highest PCI Express generation4.0

4th M.2 largest key size22110

ACPI version5.0

Antenna includedYes

ATX Power connector (24-pin)Yes

Audio ChipRealtek ALC1220

Audio output channels7.1 channels

Battery technologyLithium-Manganese Dioxide (LiMnO2)

Battery typeCR2032

Battery weight3 g

BIOS memory size256 Mbit

BIOS typeUEFI AMI

Bluetooth version5.3

Bundled softwareNorton® Internet Security (OEM version) LAN bandwidth management software

Canale audio7.1

Chipset audio integratRealtek

Clear CMOS buttonYes

Clear CMOS jumperYes

Compatible processor seriesAMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series

Component forPC

Country of originChina

CPU fan connectorYes

Depth24.4 mm

Desktop Management Interface (DMI) version2.7

DirectX version12.0

DisplayPort version1.4

DisplayPorts quantity0

ECC сompatibilityNon-ECC

EPS power connector (8-pin)Yes

Ethernet interface type2.5 Gigabit Ethernet

Ethernet LANYes

FormatATX

Front panel audio connectorYes

Front panel connectorYes

GamingDa

HDMIDa

HDMI ports quantity1

HDMI version2.1

Headphone outputs1

Height35 mm

LAN controllerRealtek RTL8125

Lithium weight per battery0.07 g

Maximum internal memory256 GB

Maximum internal memory per slot64 GB

Maximum internal memory supported by processor256 GB

Memorie maxima256 GB

Memory channelsDual-channel

Memory slots typeDIMM

Microphone inYes

Model ChipsetX870E

Motherboard chipsetAMD X870E

Motherboard chipset familyAMD

Motherboard form factorATX

mSATA ports quantity0

Numar sloturi memorie4

Number of battery cells1

Number of chassis fan connectors6

Number of CPU fan connectors2

Number of EPS power connectors (8-pin)1

Number of HDDs supported4

Number of M.2 (M) slots4

Number of memory slots4

Number of RGB LED pin headers4

Number of SATA III connectors4

Number of storage drives supported8

Number of water pump connectors2

On-board graphics cardNo

Onboard-CPUNo

Package depth294 mm

Package height80 mm

Package weight2.74 kg

Package width34.5 mm

Parallel processing technology supportNot supported

PC health monitoringFan, Temperature, Voltage

PCI0

PCI Express x1 (Gen 3.x) slots0

PCI Express x1 (Gen 4.x) slots0

PCI Express x16 (Gen 3.x) slots1

PCI Express x16 (Gen 4.x) slots1

PCI Express x16 (Gen 5.x) slots1

PCI Express x4 (Gen 3.x) slots0

PCI Express x4 (Gen 4.x) slots0

PCI Express x4 slots2

PCI Express x8 (Gen 3.x) slots0

PCI Express x8 (Gen 4.x) slots0

PCI Express x8 (Gen 5.x) slots0

Processor manufacturerAMD

Processor socketSocket AM5

PS/2 ports quantity0

RAID levels0, 1, 10

RAID supportYes

RGB LED pin headerYes

RJ-45 LAN1

S/PDIF out portYes

Screws includedYes

Serial-or-ParalelYes/No

Sloturi M.24

Soclu ProcesorSocket AM5

Supported memory clock speed (max)8200 MHz

Supported memory clock speeds4400,4800,5600,6000,6400,6600,6666,6800,7000,7200,7800,8000,8200 MHz

Supported memory module capacities1GB, 2GB, 4GB, 8GB, 12GB, 24GB, 32GB

Supported memory typesDDR5-SDRAM

Supported processor socketsSocket AM5

Supported storage drive interfacesM.2, SATA III

Supported storage drive typesHDD & SSD

System Management BIOS (SMBIOS) version2.7

ThunderboltNu

Tip MemorieDDR5

Top Wi-Fi standardWi-Fi 7 (802.11be)

TPM connectorYes

Unbuffered memoryYes

USB 2.0 connectors2

USB 2.0 ports quantity2

USB 3.2 Gen 1 (3.1 Gen 1) connectors2

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0

USB 3.2 Gen 2 (3.1 Gen 2) connectors0

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity0

USB 3.2 Gen 2x2 connectors1

USB 3.2 Gen 2x2 Type-C ports quantity0

USB Type CDa

USB4 Gen 2x2 ports quantity2

USB4 Gen 3x2 ports quantity0

Video-ConnectionHDMI

Weight2.4 kg

Wi-FIYes

Wi-Fi standardsWi-Fi 7 (802.11be)

Width30.5 mm

WiFi-AP antenna jack2

Windows operating systems supportedWindows 11 x64

WirelessDa

WLAN controller modelQualcomm QCNCM865

Specificații

Brand	GIGABYTE
Cod produs	NOD-X870E AORUS PRO
Categorie	Componente
Garanție	Se confirmă la ofertare
Livrare	5–7 zile
Bluetooth	Nu
1st M.2 highest PCI Express generation	5.0
1st M.2 largest key size	25110
2nd M.2 highest PCI Express generation	5.0
2nd M.2 largest key size	22110
3rd M.2 highest PCI Express generation	5.0
3rd M.2 largest key size	22110
4th M.2 highest PCI Express generation	4.0
4th M.2 largest key size	22110
ACPI version	5.0
Antenna included	Yes
ATX Power connector (24-pin)	Yes
Audio Chip	Realtek ALC1220
Audio output channels	7.1 channels
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Battery type	CR2032
Battery weight	3 g
BIOS memory size	256 Mbit
BIOS type	UEFI AMI
Bluetooth version	5.3
Bundled software	Norton® Internet Security (OEM version) LAN bandwidth management software
Canale audio	7.1
Chipset audio integrat	Realtek
Clear CMOS button	Yes
Clear CMOS jumper	Yes
Compatible processor series	AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Component for	PC
Country of origin	China
CPU fan connector	Yes
Depth	24.4 mm
Desktop Management Interface (DMI) version	2.7
DirectX version	12.0
DisplayPort version	1.4
DisplayPorts quantity	0
ECC сompatibility	Non-ECC
EPS power connector (8-pin)	Yes
Ethernet interface type	2.5 Gigabit Ethernet
Ethernet LAN	Yes
Format	ATX
Front panel audio connector	Yes
Front panel connector	Yes
Gaming	Da
HDMI	Da
HDMI ports quantity	1
HDMI version	2.1
Headphone outputs	1
Height	35 mm
LAN controller	Realtek RTL8125
Lithium weight per battery	0.07 g
Maximum internal memory	256 GB
Maximum internal memory per slot	64 GB
Maximum internal memory supported by processor	256 GB
Memorie maxima	256 GB
Memory channels	Dual-channel
Memory slots type	DIMM
Microphone in	Yes
Model Chipset	X870E
Motherboard chipset	AMD X870E
Motherboard chipset family	AMD
Motherboard form factor	ATX
mSATA ports quantity	0
Numar sloturi memorie	4
Number of battery cells	1
Number of chassis fan connectors	6
Number of CPU fan connectors	2
Number of EPS power connectors (8-pin)	1
Number of HDDs supported	4
Number of M.2 (M) slots	4
Number of memory slots	4
Number of RGB LED pin headers	4
Number of SATA III connectors	4
Number of storage drives supported	8
Number of water pump connectors	2
On-board graphics card	No
Onboard-CPU	No
Package depth	294 mm
Package height	80 mm
Package weight	2.74 kg
Package width	34.5 mm
Parallel processing technology support	Not supported
PC health monitoring	Fan, Temperature, Voltage
PCI	0
PCI Express x1 (Gen 3.x) slots	0
PCI Express x1 (Gen 4.x) slots	0
PCI Express x16 (Gen 3.x) slots	1
PCI Express x16 (Gen 4.x) slots	1
PCI Express x16 (Gen 5.x) slots	1
PCI Express x4 (Gen 3.x) slots	0
PCI Express x4 (Gen 4.x) slots	0
PCI Express x4 slots	2
PCI Express x8 (Gen 3.x) slots	0
PCI Express x8 (Gen 4.x) slots	0
PCI Express x8 (Gen 5.x) slots	0
Processor manufacturer	AMD
Processor socket	Socket AM5
PS/2 ports quantity	0
RAID levels	0, 1, 10
RAID support	Yes
RGB LED pin header	Yes
RJ-45 LAN	1
S/PDIF out port	Yes
Screws included	Yes
Serial-or-Paralel	Yes/No
Sloturi M.2	4
Soclu Procesor	Socket AM5
Supported memory clock speed (max)	8200 MHz
Supported memory clock speeds	4400,4800,5600,6000,6400,6600,6666,6800,7000,7200,7800,8000,8200 MHz
Supported memory module capacities	1GB, 2GB, 4GB, 8GB, 12GB, 24GB, 32GB
Supported memory types	DDR5-SDRAM
Supported processor sockets	Socket AM5
Supported storage drive interfaces	M.2, SATA III
Supported storage drive types	HDD & SSD
System Management BIOS (SMBIOS) version	2.7
Thunderbolt	Nu
Tip Memorie	DDR5
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
TPM connector	Yes
Unbuffered memory	Yes
USB 2.0 connectors	2
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
USB 3.2 Gen 2x2 connectors	1
USB 3.2 Gen 2x2 Type-C ports quantity	0
USB Type C	Da
USB4 Gen 2x2 ports quantity	2
USB4 Gen 3x2 ports quantity	0
Video-Connection	HDMI
Weight	2.4 kg
Wi-FI	Yes
Wi-Fi standards	Wi-Fi 7 (802.11be)
Width	30.5 mm
WiFi-AP antenna jack	2
Windows operating systems supported	Windows 11 x64
Wireless	Da
WLAN controller model	Qualcomm QCNCM865

Configurație

Placa de Baza GIGABYTE X870 AORUS PRO AM5, 4x DDR5, 2x USB4 1x HDMI 1x front HDMI, 3x PCIE x16, 4x M.2, 4x SATA 6GB/s, ATX

Ai nevoie de o configurație diferită? Echipa noastră o poate personaliza — Cere ofertă.

Prezentare detaliată

Placa de Baza GIGABYTE X870 AORUS PRO AM5, 4x DDR5, 2x USB4 1x HDMI 1x front HDMI, 3x PCIE x16, 4x M.2, 4x SATA 6GB/s, ATX

Bluetooth: Nu1st M.2 highest PCI Express generation: 5.01st M.2 largest key size: 251102nd M.2 highest PCI Express generation: 5.02nd M.2 largest key size: 221103rd M.2 highest PCI Express generation: 5.0
