Placa de baza Gigabyte B860 AORUS ELITE WIFI7 ICE, Socket 1851, DDR5, ATX

GIGABYTE · NOD-B860 A ELITE WF7 ICE

Placa de baza Gigabyte B860 AORUS ELITE WIFI7 ICE, Socket 1851, DDR5, ATX

Name: Placa de baza Gigabyte B860 AORUS ELITE WIFI7 ICE, Socket 1851, DDR5, ATX
Brand: GIGABYTE
SKU: NOD-B860 A ELITE WF7 ICE
Price: 1321 RON
Availability: InStock

Placa de Baza GIGABYTE B860 AORUS ELITE WIFI7 ICE LGA1851, 4x DDR5, 1x USB4 1x DP 1x HDMI 1x Front HDMI, 3x PCIE x16, 3x M.2, 4x SATA 6GB/s, ATX

1.092 lei

prețuri fără TVA · 1.321 lei cu TVA

Disponibil la furnizor · 6 buc·termen de livrare confirmat la comandă

Produs disponibil doar cu cont de firmă verificat. Creează cont B2B →

Cantitate

Preț de volum de la 5 buc. — cere ofertă

Total 1 buc.1.092 lei

GIGABYTE · ComponenteDoar pentru firme (B2B)

Placa de baza Gigabyte B860 AORUS ELITE WIFI7 ICE, Socket 1851, DDR5, ATX

SKU: NOD-B860 A ELITE WF7 ICE

Bluetooth: Da
1st M.2 highest PCI Express generation: 5.0
1st M.2 largest key size: 25110
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 22110
3rd M.2 highest PCI Express generation: 4.0

Prețuri de volum

Pentru 5+ bucăți primești preț negociat — trimite o cerere de ofertă din coș.

1.092 leiprețuri fără TVA

Disponibil la furnizor · 6 buc·termen de livrare confirmat la comandă

Cere ofertă pentru volum

Acest produs se poate comanda doar cu cont de firmă verificat. Creează cont B2B →

Retur gratuit 30 de zileFactură fiscală automatăGaranție de producător

BrandGIGABYTE

Cod produsNOD-B860 A ELITE WF7 ICE

CategorieComponente

BluetoothDa

1st M.2 highest PCI Express generation5.0

1st M.2 largest key size25110

2nd M.2 highest PCI Express generation4.0

2nd M.2 largest key size22110

3rd M.2 highest PCI Express generation4.0

3rd M.2 largest key size22110

ACPI version5.0

Antenna includedYes

ATX Power connector (24-pin)Yes

Audio ChipRealtek ALC897

Audio output channels7.1 channels

Battery technologyLithium-Manganese Dioxide (LiMnO2)

Battery typeCR2032

Battery weight3 g

BIOS memory size256 Mbit

BIOS typeUEFI AMI

Bluetooth version5.4

Bundled softwareNorton® Internet Security (OEM version) LAN bandwidth management software

Canale audio7.1

Chipset audio integratRealtek

Clear CMOS jumperYes

Compatible processor seriesIntel® Core™ Ultra (Series 1), Intel Core Ultra (Series 2)

Component forPC

Country of originChina

CPU fan connectorYes

Depth24.4 mm

Desktop Management Interface (DMI) version2.7

Digital audio optical out1

DirectX version12.0

DisplayPort version2.1

DisplayPorts quantity1

DVI-D ports quantity0

ECC сompatibilityECC & Non-ECC

EPS power connector (8-pin)Yes

Ethernet interface type2.5 Gigabit Ethernet

Ethernet LANYes

FormatATX

Front panel audio connectorYes

Front panel connectorYes

GamingDa

HDCPYes

HDMIDa

HDMI ports quantity1

HDMI version2.1

Headphone outputs1

Height35 mm

LAN controllerRealtek RTL8125

Line-inYes

Lithium weight per battery0.07 g

Maximum internal memory256 GB

Maximum internal memory per slot64 GB

Maximum resolution4096 x 2160 pixels

Memorie maxima256 GB

Memory channelsDual-channel

Memory slots typeDIMM

Model ChipsetB860

Motherboard chipsetIntel B860

Motherboard chipset familyIntel

Motherboard form factorATX

Numar sloturi memorie4

Number of battery cells1

Number of chassis fan connectors4

Number of CPU fan connectors2

Number of EPS power connectors (8-pin)2

Number of HDDs supported4

Number of M.2 (M) slots3

Number of memory slots4

Number of RGB LED pin headers4

Number of SATA III connectors4

Number of storage drives supported7

Number of water pump connectors2

Onboard-CPUNo

Package depth270 mm

Package height80 mm

Package weight2.49 kg

Package width335 mm

Parallel processing technology supportNot supported

PC health monitoringFan, Temperature, Voltage, Water cooling

PCI0

PCI Express x16 (Gen 4.x) slots2

PCI Express x16 (Gen 5.x) slots1

Power source typeATX

Processor manufacturerIntel

Processor socketLGA 1851 (Socket V1)

Product colourWhite

RAID levels0, 1, 5, 10

RAID supportYes

RGB LED pin headerYes

RJ-45 LAN1

S/PDIF out portYes

Screws includedYes

Serial-or-ParalelNo/No

Sloturi M.23

Soclu ProcesorSocket 1851

Supported memory clock speed (max)9200 MHz

Supported memory clock speeds5600,6400,9200 MHz

Supported memory typesDDR5-SDRAM

Supported processor socketsLGA 1851

Supported storage drive interfacesM.2, SATA III

Supported storage drive typesHDD & SSD

System Management BIOS (SMBIOS) version2.7

ThunderboltNu

Tip MemorieDDR5

Top Wi-Fi standardWi-Fi 7 (802.11be)

TPM connectorYes

Unbuffered memoryYes

USB 2.0 connectors2

USB 2.0 ports quantity4

USB 3.2 Gen 1 (3.1 Gen 1) connectors1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0

USB 3.2 Gen 2 (3.1 Gen 2) connectors1

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity0

USB Type CDa

USB4 Gen 2x2 ports quantity1

VGA (D-Sub) ports quantity0

Video-ConnectionHDMI/DP

Weight2.21 kg

Wi-FIYes

Width30.5 mm

WiFi-AP antenna jack2

Windows operating systems supportedWindows 11 x64

WirelessDa

WLAN controller modelRealtek RTL8922AE

Specificații

Brand	GIGABYTE
Cod produs	NOD-B860 A ELITE WF7 ICE
Categorie	Componente
Garanție	Se confirmă la ofertare
Livrare	termen de livrare confirmat la comandă
Bluetooth	Da
1st M.2 highest PCI Express generation	5.0
1st M.2 largest key size	25110
2nd M.2 highest PCI Express generation	4.0
2nd M.2 largest key size	22110
3rd M.2 highest PCI Express generation	4.0
3rd M.2 largest key size	22110
ACPI version	5.0
Antenna included	Yes
ATX Power connector (24-pin)	Yes
Audio Chip	Realtek ALC897
Audio output channels	7.1 channels
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Battery type	CR2032
Battery weight	3 g
BIOS memory size	256 Mbit
BIOS type	UEFI AMI
Bluetooth version	5.4
Bundled software	Norton® Internet Security (OEM version) LAN bandwidth management software
Canale audio	7.1
Chipset audio integrat	Realtek
Clear CMOS jumper	Yes
Compatible processor series	Intel® Core™ Ultra (Series 1), Intel Core Ultra (Series 2)
Component for	PC
Country of origin	China
CPU fan connector	Yes
Depth	24.4 mm
Desktop Management Interface (DMI) version	2.7
Digital audio optical out	1
DirectX version	12.0
DisplayPort version	2.1
DisplayPorts quantity	1
DVI-D ports quantity	0
ECC сompatibility	ECC & Non-ECC
EPS power connector (8-pin)	Yes
Ethernet interface type	2.5 Gigabit Ethernet
Ethernet LAN	Yes
Format	ATX
Front panel audio connector	Yes
Front panel connector	Yes
Gaming	Da
HDCP	Yes
HDMI	Da
HDMI ports quantity	1
HDMI version	2.1
Headphone outputs	1
Height	35 mm
LAN controller	Realtek RTL8125
Line-in	Yes
Lithium weight per battery	0.07 g
Maximum internal memory	256 GB
Maximum internal memory per slot	64 GB
Maximum resolution	4096 x 2160 pixels
Memorie maxima	256 GB
Memory channels	Dual-channel
Memory slots type	DIMM
Model Chipset	B860
Motherboard chipset	Intel B860
Motherboard chipset family	Intel
Motherboard form factor	ATX
Numar sloturi memorie	4
Number of battery cells	1
Number of chassis fan connectors	4
Number of CPU fan connectors	2
Number of EPS power connectors (8-pin)	2
Number of HDDs supported	4
Number of M.2 (M) slots	3
Number of memory slots	4
Number of RGB LED pin headers	4
Number of SATA III connectors	4
Number of storage drives supported	7
Number of water pump connectors	2
Onboard-CPU	No
Package depth	270 mm
Package height	80 mm
Package weight	2.49 kg
Package width	335 mm
Parallel processing technology support	Not supported
PC health monitoring	Fan, Temperature, Voltage, Water cooling
PCI	0
PCI Express x16 (Gen 4.x) slots	2
PCI Express x16 (Gen 5.x) slots	1
Power source type	ATX
Processor manufacturer	Intel
Processor socket	LGA 1851 (Socket V1)
Product colour	White
RAID levels	0, 1, 5, 10
RAID support	Yes
RGB LED pin header	Yes
RJ-45 LAN	1
S/PDIF out port	Yes
Screws included	Yes
Serial-or-Paralel	No/No
Sloturi M.2	3
Soclu Procesor	Socket 1851
Supported memory clock speed (max)	9200 MHz
Supported memory clock speeds	5600,6400,9200 MHz
Supported memory types	DDR5-SDRAM
Supported processor sockets	LGA 1851
Supported storage drive interfaces	M.2, SATA III
Supported storage drive types	HDD & SSD
System Management BIOS (SMBIOS) version	2.7
Thunderbolt	Nu
Tip Memorie	DDR5
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
TPM connector	Yes
Unbuffered memory	Yes
USB 2.0 connectors	2
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) connectors	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
USB Type C	Da
USB4 Gen 2x2 ports quantity	1
VGA (D-Sub) ports quantity	0
Video-Connection	HDMI/DP
Weight	2.21 kg
Wi-FI	Yes
Width	30.5 mm
WiFi-AP antenna jack	2
Windows operating systems supported	Windows 11 x64
Wireless	Da
WLAN controller model	Realtek RTL8922AE

Configurație

Placa de Baza GIGABYTE B860 AORUS ELITE WIFI7 ICE LGA1851, 4x DDR5, 1x USB4 1x DP 1x HDMI 1x Front HDMI, 3x PCIE x16, 3x M.2, 4x SATA 6GB/s, ATX

Ai nevoie de o configurație diferită? Echipa noastră o poate personaliza — Cere ofertă.

Prezentare detaliată

Placa de Baza GIGABYTE B860 AORUS ELITE WIFI7 ICE LGA1851, 4x DDR5, 1x USB4 1x DP 1x HDMI 1x Front HDMI, 3x PCIE x16, 3x M.2, 4x SATA 6GB/s, ATX

Bluetooth: Da1st M.2 highest PCI Express generation: 5.01st M.2 largest key size: 251102nd M.2 highest PCI Express generation: 4.02nd M.2 largest key size: 221103rd M.2 highest PCI Express generation: 4.0
