Placa de baza Gigabyte B760M DS3H AX, Socket 1700, DDR5, Micro-ATX

GIGABYTE · NOD-B760M DS3H AX

Placa de baza Gigabyte B760M DS3H AX, Socket 1700, DDR5, Micro-ATX

Name: Placa de baza Gigabyte B760M DS3H AX, Socket 1700, DDR5, Micro-ATX
Brand: GIGABYTE
SKU: NOD-B760M DS3H AX
Price: 1042 RON
Availability: BackOrder

Placa de baza GIGABYTE B760M DS3H AX (rev. 1.x) LGA1700, 4x DDR5, 1x PCIE x16, 2x PCIE x1, 2x M.2, 1x HDMI 2X DP, 4x SATA 6GB/s, mATX

861 lei

prețuri fără TVA · 1.042 lei cu TVA

La comandă·5–7 zile

Produs disponibil doar cu cont de firmă verificat. Creează cont B2B →

Cantitate

Preț de volum de la 5 buc. — cere ofertă

Total 1 buc.861 lei

GIGABYTE · ComponenteDoar pentru firme (B2B)

Placa de baza Gigabyte B760M DS3H AX, Socket 1700, DDR5, Micro-ATX

SKU: NOD-B760M DS3H AX

Bluetooth: Nu
12V power connector: Yes
1st M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 2280

Prețuri de volum

Pentru 5+ bucăți primești preț negociat — trimite o cerere de ofertă din coș.

861 leiprețuri fără TVA

La comandă·5–7 zile

Cere ofertă pentru volum

Acest produs se poate comanda doar cu cont de firmă verificat. Creează cont B2B →

Retur gratuit 30 de zileFactură fiscală automatăGaranție de producător

BrandGIGABYTE

Cod produsNOD-B760M DS3H AX

CategorieComponente

BluetoothNu

12V power connectorYes

1st M.2 highest PCI Express generation4.0

1st M.2 largest key size2280

2nd M.2 highest PCI Express generation4.0

2nd M.2 largest key size2280

ACPI version5.0

ATX Power connector (24-pin)Yes

Audio output channels7.1 channels

Batteries includedYes

Battery technologyLithium-Manganese Dioxide (LiMnO2)

Battery typeCR2032

Battery weight3 g

BIOS memory size128 Mbit

BIOS typeUEFI AMI

Bluetooth version5.3

Bundled softwareNorton Internet Security

Cables includedSATA

Canale audio7.1

Chipset audio integratRealtek

Clear CMOS jumperYes

Component forPC

Country of originChina

CPU fan connectorYes

Depth24.4 mm

Desktop Management Interface (DMI) version2.7

DirectX version12.0

DisplayPorts quantity2

DVI-D ports quantity0

ECC сompatibilityECC & Non-ECC

EPS power connector (8-pin)Yes

Ethernet interface type2.5 Gigabit Ethernet

Ethernet LANYes

Ethernet LAN (RJ-45) ports1

FormatMicro-ATX

Front panel audio connectorYes

Front panel connectorYes

GamingNu

HDCPYes

HDMIDa

HDMI ports quantity1

Headphone outputs3

Height35 mm

Lithium weight per battery0.07 g

Maximum internal memory256 GB

Maximum internal memory supported by processor192 GB

Maximum resolution4096 x 2304 pixels

Memorie maxima192 GB

Memory channelsDual-channel

Memory slots typeDIMM

Microphone inYes

Model ChipsetB760

Motherboard chipsetIntel B760 Express

Motherboard chipset familyIntel

Motherboard form factormicro ATX

Numar sloturi memorie4

Number of battery cells1

Number of HDDs supported4

Number of M.2 (M) slots2

Number of memory slots4

Number of SATA III connectors4

Number of storage drives supported6

Onboard-CPUNo

Package depth265 mm

Package height54 mm

Package weight1.1 kg

Package width265 mm

Parallel processing technology supportNot supported

PC health monitoringFan, Temperature, Voltage, Water cooling

PCI0

PCI Express x1 (Gen 2.x) slots1

PCI Express x16 (Gen 4.x) slots1

PCI Express x16 slots1

Processor manufacturerIntel

Processor socketLGA 1700

Product colourBrown

Products per shipping (inner) case1 pc(s)

PS/2 ports quantity1

RAID levels0, 1, 5, 10

RAID supportYes

RGB LED pin headerYes

RJ-45 LAN1

S/PDIF out connectorYes

Serial-or-ParalelNo/No

Sloturi M.22

Soclu ProcesorSocket 1700

Supported memory clock speed (max)7600 MHz

Supported memory clock speeds4000,4800,5200,5400,5600,5800,6000,6200,6400,6800,7000,7200,7400,7600 MHz

Supported memory module capacities1GB, 2GB, 4GB, 8GB, 12GB, 16GB, 32GB, 48GB

Supported memory typesDDR5-SDRAM

Supported processor socketsLGA 1700

Supported storage drive interfacesM.2, SATA III

Supported storage drive typesHDD & SSD

System Management BIOS (SMBIOS) version2.7

ThunderboltNu

Tip MemorieDDR5

Tip slot interfata graficaPCIe 4.0 x16

Top Wi-Fi standardWi-Fi 6E (802.11ax)

Total number of SATA connectors4

TPM connectorYes

Unbuffered memoryYes

USB 2.0 connectors2

USB 2.0 ports quantity2

USB 3.2 Gen 1 (3.1 Gen 1) connectors1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0

USB 3.2 Gen 2 (3.1 Gen 2) connectors0

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity0

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1

USB connector typeUSB Type-A, USB Type-C

USB Type CDa

VGA (D-Sub) ports quantity0

Video-ConnectionDP

Warranty period3 year(s)

Wi-FIYes

Width244 mm

WiFi-AP antenna jack2

Windows operating systems supportedWindows 10 x64, Windows 11 x64

WirelessDa

WLAN controller modelIntel Wi-Fi 6E AX211

Specificații

Brand	GIGABYTE
Cod produs	NOD-B760M DS3H AX
Categorie	Componente
Garanție	Se confirmă la ofertare
Livrare	5–7 zile
Bluetooth	Nu
12V power connector	Yes
1st M.2 highest PCI Express generation	4.0
1st M.2 largest key size	2280
2nd M.2 highest PCI Express generation	4.0
2nd M.2 largest key size	2280
ACPI version	5.0
ATX Power connector (24-pin)	Yes
Audio output channels	7.1 channels
Batteries included	Yes
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Battery type	CR2032
Battery weight	3 g
BIOS memory size	128 Mbit
BIOS type	UEFI AMI
Bluetooth version	5.3
Bundled software	Norton Internet Security
Cables included	SATA
Canale audio	7.1
Chipset audio integrat	Realtek
Clear CMOS jumper	Yes
Component for	PC
Country of origin	China
CPU fan connector	Yes
Depth	24.4 mm
Desktop Management Interface (DMI) version	2.7
DirectX version	12.0
DisplayPorts quantity	2
DVI-D ports quantity	0
ECC сompatibility	ECC & Non-ECC
EPS power connector (8-pin)	Yes
Ethernet interface type	2.5 Gigabit Ethernet
Ethernet LAN	Yes
Ethernet LAN (RJ-45) ports	1
Format	Micro-ATX
Front panel audio connector	Yes
Front panel connector	Yes
Gaming	Nu
HDCP	Yes
HDMI	Da
HDMI ports quantity	1
Headphone outputs	3
Height	35 mm
Lithium weight per battery	0.07 g
Maximum internal memory	256 GB
Maximum internal memory supported by processor	192 GB
Maximum resolution	4096 x 2304 pixels
Memorie maxima	192 GB
Memory channels	Dual-channel
Memory slots type	DIMM
Microphone in	Yes
Model Chipset	B760
Motherboard chipset	Intel B760 Express
Motherboard chipset family	Intel
Motherboard form factor	micro ATX
Numar sloturi memorie	4
Number of battery cells	1
Number of HDDs supported	4
Number of M.2 (M) slots	2
Number of memory slots	4
Number of SATA III connectors	4
Number of storage drives supported	6
Onboard-CPU	No
Package depth	265 mm
Package height	54 mm
Package weight	1.1 kg
Package width	265 mm
Parallel processing technology support	Not supported
PC health monitoring	Fan, Temperature, Voltage, Water cooling
PCI	0
PCI Express x1 (Gen 2.x) slots	1
PCI Express x16 (Gen 4.x) slots	1
PCI Express x16 slots	1
Processor manufacturer	Intel
Processor socket	LGA 1700
Product colour	Brown
Products per shipping (inner) case	1 pc(s)
PS/2 ports quantity	1
RAID levels	0, 1, 5, 10
RAID support	Yes
RGB LED pin header	Yes
RJ-45 LAN	1
S/PDIF out connector	Yes
Serial-or-Paralel	No/No
Sloturi M.2	2
Soclu Procesor	Socket 1700
Supported memory clock speed (max)	7600 MHz
Supported memory clock speeds	4000,4800,5200,5400,5600,5800,6000,6200,6400,6800,7000,7200,7400,7600 MHz
Supported memory module capacities	1GB, 2GB, 4GB, 8GB, 12GB, 16GB, 32GB, 48GB
Supported memory types	DDR5-SDRAM
Supported processor sockets	LGA 1700
Supported storage drive interfaces	M.2, SATA III
Supported storage drive types	HDD & SSD
System Management BIOS (SMBIOS) version	2.7
Thunderbolt	Nu
Tip Memorie	DDR5
Tip slot interfata grafica	PCIe 4.0 x16
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Total number of SATA connectors	4
TPM connector	Yes
Unbuffered memory	Yes
USB 2.0 connectors	2
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
USB connector type	USB Type-A, USB Type-C
USB Type C	Da
VGA (D-Sub) ports quantity	0
Video-Connection	DP
Warranty period	3 year(s)
Wi-FI	Yes
Width	244 mm
WiFi-AP antenna jack	2
Windows operating systems supported	Windows 10 x64, Windows 11 x64
Wireless	Da
WLAN controller model	Intel Wi-Fi 6E AX211

Configurație

Placa de baza GIGABYTE B760M DS3H AX (rev. 1.x) LGA1700, 4x DDR5, 1x PCIE x16, 2x PCIE x1, 2x M.2, 1x HDMI 2X DP, 4x SATA 6GB/s, mATX

Ai nevoie de o configurație diferită? Echipa noastră o poate personaliza — Cere ofertă.

Prezentare detaliată

Placa de baza GIGABYTE B760M DS3H AX (rev. 1.x) LGA1700, 4x DDR5, 1x PCIE x16, 2x PCIE x1, 2x M.2, 1x HDMI 2X DP, 4x SATA 6GB/s, mATX

Bluetooth: Nu12V power connector: Yes1st M.2 highest PCI Express generation: 4.01st M.2 largest key size: 22802nd M.2 highest PCI Express generation: 4.02nd M.2 largest key size: 2280
