GIGABYTE · NOD-B650M GAMING PLUS WF

Placa de baza Gigabyte B650M GAMING PLUS WIFI, Socket AM5, DDR5, mATX

Name: Placa de baza Gigabyte B650M GAMING PLUS WIFI, Socket AM5, DDR5, mATX
Brand: GIGABYTE
SKU: NOD-B650M GAMING PLUS WF
Price: 728 RON
Availability: BackOrder

Placa de Baza GIGABYTE B650M GAMING PLUS WIFI AM5, 4x DDR5, 2x DP 1x HDMI, 1x PCIE 4.0 x16 1x PCIE 3.0 x1, 2x M.2, 4x SATA 6GB/s, mATX

602 lei

prețuri fără TVA · 728 lei cu TVA

La comandă·5–7 zile

Produs disponibil doar cu cont de firmă verificat. Creează cont B2B →

Cantitate

Preț de volum de la 5 buc. — cere ofertă

Total 1 buc.602 lei

GIGABYTE · ComponenteDoar pentru firme (B2B)

Placa de baza Gigabyte B650M GAMING PLUS WIFI, Socket AM5, DDR5, mATX

SKU: NOD-B650M GAMING PLUS WF

Bluetooth: Da
1st M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2580
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 22110
ACPI version: 5.0

Prețuri de volum

Pentru 5+ bucăți primești preț negociat — trimite o cerere de ofertă din coș.

602 leiprețuri fără TVA

La comandă·5–7 zile

Cere ofertă pentru volum

Acest produs se poate comanda doar cu cont de firmă verificat. Creează cont B2B →

Retur gratuit 30 de zileFactură fiscală automatăGaranție de producător

BrandGIGABYTE

Cod produsNOD-B650M GAMING PLUS WF

CategorieComponente

BluetoothDa

1st M.2 highest PCI Express generation4.0

1st M.2 largest key size2580

2nd M.2 highest PCI Express generation4.0

2nd M.2 largest key size22110

ACPI version5.0

Alte specificatiiSuporta profil de memorie Intel XMP, AMD EXPO

Antenna includedYes

ATX Power connector (24-pin)Yes

Audio ChipRealtek ALC897

Audio jacks3

Audio output channels7.1 channels

Battery technologyLithium-Manganese Dioxide (LiMnO2)

Battery typeCR2032

Battery weight3 g

BIOS256 Mbit AMI UEFI BIOS

BIOS memory size256 Mbit

BIOS typeUEFI AMI

Bluetooth version5.3

Bundled softwareNorton® Internet Security (OEM version) LAN bandwidth management software

Canale audio7.1

Capacitate maxima memorie RAM256 GB

ChipsetB650

Chipset audioRealtek ALC897

Chipset audio integratRealtek

Chipset reteaRealtek RTL8125BG

Clear CMOS jumperYes

Compatible processor seriesAMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series

Component forPC

Conectori speciali2 x conectori antena 2T2R

Cooling typePassive

CPU fan connectorYes

CPU SocketAM5

Depth24.4 mm

Desktop Management Interface (DMI) version2.7

Dimensiuni (L x l, cm)24.4 x 24.4 cm

DirectX version12.0

DisplayPort2

DisplayPort version1.4

DisplayPorts quantity2

DVI-D ports quantity0

ECC сompatibilityNon-ECC

EPS power connector (8-pin)Yes

Ethernet interface type2.5 Gigabit Ethernet

Ethernet LANYes

FormatmATX

Frecvente suportate8000(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800 MHz

Front panel audio connectorYes

Front panel connectorYes

GamingDa

HDCPYes

HDMI1

HDMI ports quantity1

HDMI version2.1

Header USB 3.0Da

Headphone outputs1

Height35 mm

Interfata graficaPCI Express x16 4.0

LAN controllerRealtek RTL8125

Line-inYes

Lithium weight per battery0.07 g

Maximum internal memory256 GB

Maximum internal memory per slot64 GB

Maximum resolution4096 x 2160 pixels

MB-Formatmicro-ATX

MB-SocketAM5

Memorie maxima256 GB

Memory channelsDual-channel

Memory slots typeDIMM

Microphone inYes

Model ChipsetB650

Model memorieDDR5

Motherboard chipsetAMD B650

Motherboard chipset familyAMD

Motherboard form factormicro ATX

NGFF (M.2)2

Numar sloturi memorie4

Number of battery cells1

Number of chassis fan connectors2

Number of CPU fan connectors1

Number of EPS power connectors (8-pin)1

Number of HDDs supported4

Number of M.2 (M) slots2

Number of memory slots4

Number of RGB LED pin headers3

Number of SATA III connectors4

Number of storage drives supported6

Onboard-CPUNo

Package depth268 mm

Package height68 mm

Package weight1.53 kg

Package width270 mm

Parallel processing technology supportNot supported

PC health monitoringFan, Temperature, Voltage

PCI0

PCI Express 4.01 (x16)

PCI Express x12

PCI Express x1 (Gen 3.x) slots1

PCI Express x16 (Gen 4.x) slots1

PCI-Ex11

PCI-Ex161

Placa audio integrata7.1 Audio

Placa retea integrata2.5 Gbps

Placa video integrataNecesita procesor cu tehnologia AMD Radeon Graphics

Power source typeATX

Procesoare suportateAMD Ryzen 7000/8000/9000 Series

Processor manufacturerAMD

Processor socketSocket AM5

Producator chipsetAMD

Product colourDark brown

PS/2 Combo Mouse/Tastatura1

PS/2 ports quantity1

RAID0, 1, 10

RAID levels0, 1, 10

RAID supportYes

RAM-Slots4

Recomandat GamingDa

RGB LED pin headerYes

RJ-451

RJ-45 LAN1

SATA III4

Screws includedYes

Serial-or-ParalelNo/No

Sloturi M.22

Sloturi memorie4

Soclu ProcesorSocket AM5

Suport audio7.1

Supported memory clock speed (max)8000 MHz

Supported memory clock speeds8000,7800,7600,7200,7000,6800,6600,6400,6200,6000,5600,5200,4800 MHz

Supported memory typesDDR5-SDRAM

Supported processor socketsSocket AM5

Supported storage drive interfacesM.2, PCI Express 4.0, SATA III

Supported storage drive typesHDD & SSD

System Management BIOS (SMBIOS) version2.7

TehnologieDual channel

ThunderboltNu

Tip MemorieDDR5

Tip slot interfata graficaPCIe 4.0 x16

Top Wi-Fi standardWi-Fi 6E (802.11ax)

TPM connectorYes

Unbuffered memoryYes

USB 2.02

USB 2.0 connectors2

USB 2.0 ports quantity2

USB 3.2 Gen 1 (3.1 Gen 1) connectors2

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity1

USB 3.2 Gen 2 (3.1 Gen 2) connectors0

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity0

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity0

USB 3.2 Gen1 tip A3

USB Tip C1

USB Type CDa

USB34-8

VGA (D-Sub) ports quantity0

Video-ConnectionHDMI/DP

Weight1.44 kg

Wi-FIYes

Width244 mm

WiFi-AP antenna jack2

Windows operating systems supportedWindows 10 x64, Windows 11 x64

WirelessDa

WLAN controller modelRealtek RTL8852CE

Specificații

Brand	GIGABYTE
Cod produs	NOD-B650M GAMING PLUS WF
Categorie	Componente
Garanție	Se confirmă la ofertare
Livrare	5–7 zile
Bluetooth	Da
1st M.2 highest PCI Express generation	4.0
1st M.2 largest key size	2580
2nd M.2 highest PCI Express generation	4.0
2nd M.2 largest key size	22110
ACPI version	5.0
Alte specificatii	Suporta profil de memorie Intel XMP, AMD EXPO
Antenna included	Yes
ATX Power connector (24-pin)	Yes
Audio Chip	Realtek ALC897
Audio jacks	3
Audio output channels	7.1 channels
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Battery type	CR2032
Battery weight	3 g
BIOS	256 Mbit AMI UEFI BIOS
BIOS memory size	256 Mbit
BIOS type	UEFI AMI
Bluetooth version	5.3
Bundled software	Norton® Internet Security (OEM version) LAN bandwidth management software
Canale audio	7.1
Capacitate maxima memorie RAM	256 GB
Chipset	B650
Chipset audio	Realtek ALC897
Chipset audio integrat	Realtek
Chipset retea	Realtek RTL8125BG
Clear CMOS jumper	Yes
Compatible processor series	AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Component for	PC
Conectori speciali	2 x conectori antena 2T2R
Cooling type	Passive
CPU fan connector	Yes
CPU Socket	AM5
Depth	24.4 mm
Desktop Management Interface (DMI) version	2.7
Dimensiuni (L x l, cm)	24.4 x 24.4 cm
DirectX version	12.0
DisplayPort	2
DisplayPort version	1.4
DisplayPorts quantity	2
DVI-D ports quantity	0
ECC сompatibility	Non-ECC
EPS power connector (8-pin)	Yes
Ethernet interface type	2.5 Gigabit Ethernet
Ethernet LAN	Yes
Format	mATX
Frecvente suportate	8000(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800 MHz
Front panel audio connector	Yes
Front panel connector	Yes
Gaming	Da
HDCP	Yes
HDMI	1
HDMI ports quantity	1
HDMI version	2.1
Header USB 3.0	Da
Headphone outputs	1
Height	35 mm
Interfata grafica	PCI Express x16 4.0
LAN controller	Realtek RTL8125
Line-in	Yes
Lithium weight per battery	0.07 g
Maximum internal memory	256 GB
Maximum internal memory per slot	64 GB
Maximum resolution	4096 x 2160 pixels
MB-Format	micro-ATX
MB-Socket	AM5
Memorie maxima	256 GB
Memory channels	Dual-channel
Memory slots type	DIMM
Microphone in	Yes
Model Chipset	B650
Model memorie	DDR5
Motherboard chipset	AMD B650
Motherboard chipset family	AMD
Motherboard form factor	micro ATX
NGFF (M.2)	2
Numar sloturi memorie	4
Number of battery cells	1
Number of chassis fan connectors	2
Number of CPU fan connectors	1
Number of EPS power connectors (8-pin)	1
Number of HDDs supported	4
Number of M.2 (M) slots	2
Number of memory slots	4
Number of RGB LED pin headers	3
Number of SATA III connectors	4
Number of storage drives supported	6
Onboard-CPU	No
Package depth	268 mm
Package height	68 mm
Package weight	1.53 kg
Package width	270 mm
Parallel processing technology support	Not supported
PC health monitoring	Fan, Temperature, Voltage
PCI	0
PCI Express 4.0	1 (x16)
PCI Express x1	2
PCI Express x1 (Gen 3.x) slots	1
PCI Express x16 (Gen 4.x) slots	1
PCI-Ex1	1
PCI-Ex16	1
Placa audio integrata	7.1 Audio
Placa retea integrata	2.5 Gbps
Placa video integrata	Necesita procesor cu tehnologia AMD Radeon Graphics
Power source type	ATX
Procesoare suportate	AMD Ryzen 7000/8000/9000 Series
Processor manufacturer	AMD
Processor socket	Socket AM5
Producator chipset	AMD
Product colour	Dark brown
PS/2 Combo Mouse/Tastatura	1
PS/2 ports quantity	1
RAID	0, 1, 10
RAID levels	0, 1, 10
RAID support	Yes
RAM-Slots	4
Recomandat Gaming	Da
RGB LED pin header	Yes
RJ-45	1
RJ-45 LAN	1
SATA III	4
Screws included	Yes
Serial-or-Paralel	No/No
Sloturi M.2	2
Sloturi memorie	4
Soclu Procesor	Socket AM5
Suport audio	7.1
Supported memory clock speed (max)	8000 MHz
Supported memory clock speeds	8000,7800,7600,7200,7000,6800,6600,6400,6200,6000,5600,5200,4800 MHz
Supported memory types	DDR5-SDRAM
Supported processor sockets	Socket AM5
Supported storage drive interfaces	M.2, PCI Express 4.0, SATA III
Supported storage drive types	HDD & SSD
System Management BIOS (SMBIOS) version	2.7
Tehnologie	Dual channel
Thunderbolt	Nu
Tip Memorie	DDR5
Tip slot interfata grafica	PCIe 4.0 x16
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
TPM connector	Yes
Unbuffered memory	Yes
USB 2.0	2
USB 2.0 connectors	2
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
USB 3.2 Gen1 tip A	3
USB Tip C	1
USB Type C	Da
USB3	4-8
VGA (D-Sub) ports quantity	0
Video-Connection	HDMI/DP
Weight	1.44 kg
Wi-FI	Yes
Width	244 mm
WiFi-AP antenna jack	2
Windows operating systems supported	Windows 10 x64, Windows 11 x64
Wireless	Da
WLAN controller model	Realtek RTL8852CE

Configurație

Placa de Baza GIGABYTE B650M GAMING PLUS WIFI AM5, 4x DDR5, 2x DP 1x HDMI, 1x PCIE 4.0 x16 1x PCIE 3.0 x1, 2x M.2, 4x SATA 6GB/s, mATX

Ai nevoie de o configurație diferită? Echipa noastră o poate personaliza — Cere ofertă.

Prezentare detaliată

Placa de Baza GIGABYTE B650M GAMING PLUS WIFI AM5, 4x DDR5, 2x DP 1x HDMI, 1x PCIE 4.0 x16 1x PCIE 3.0 x1, 2x M.2, 4x SATA 6GB/s, mATX

Bluetooth: Da1st M.2 highest PCI Express generation: 4.01st M.2 largest key size: 25802nd M.2 highest PCI Express generation: 4.02nd M.2 largest key size: 22110ACPI version: 5.0
