Placa de baza ASRock Z790 PG Lightning D4, Socket 1700, DDR4, ATX

ASROCK · NOD-Z790 PG LIGHTN/D4

Placa de baza ASRock Z790 PG Lightning D4, Socket 1700, DDR4, ATX

Name: Placa de baza ASRock Z790 PG Lightning D4, Socket 1700, DDR4, ATX
Brand: ASROCK
SKU: NOD-Z790 PG LIGHTN/D4
Price: 1344 RON
Availability: BackOrder

Placa de baza AsRock Z790 PG LIGHTNING LGA 1700, 4x DDR4, 1x HDMI 2.1, 1x eDP 1.4, 2x PCIe x16, 3x PCIe 3.0 x1, 3x M.2, 4x SATA, 2.5 Gigabit LAN, ATX

1.111 lei

prețuri fără TVA · 1.344 lei cu TVA

La comandă·5–7 zile

Produs disponibil doar cu cont de firmă verificat. Creează cont B2B →

Cantitate

Preț de volum de la 5 buc. — cere ofertă

Total 1 buc.1.111 lei

ASROCK · ComponenteDoar pentru firme (B2B)

Placa de baza ASRock Z790 PG Lightning D4, Socket 1700, DDR4, ATX

SKU: NOD-Z790 PG LIGHTN/D4

Bluetooth: Nu
ATX Power connector (24-pin): Yes
Audio Chip: Realtek ALC897
Audio output channels: 7.1 channels
BIOS memory size: 128 Mbit
BIOS type: UEFI AMI

Prețuri de volum

Pentru 5+ bucăți primești preț negociat — trimite o cerere de ofertă din coș.

1.111 leiprețuri fără TVA

La comandă·5–7 zile

Cere ofertă pentru volum

Acest produs se poate comanda doar cu cont de firmă verificat. Creează cont B2B →

Retur gratuit 30 de zileFactură fiscală automatăGaranție de producător

BrandASROCK

Cod produsNOD-Z790 PG LIGHTN/D4

CategorieComponente

BluetoothNu

ATX Power connector (24-pin)Yes

Audio ChipRealtek ALC897

Audio output channels7.1 channels

BIOS memory size128 Mbit

BIOS typeUEFI AMI

Canale audio7.1

Chipset audio integratRealtek

Compatible processor seriesIntel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9

Component forPC

CPU fan connectorYes

Depth24.4 mm

DVI-D ports quantity0

ECC сompatibilityNon-ECC

Ethernet interface type2.5 Gigabit Ethernet

Ethernet LANYes

Ethernet LAN (RJ-45) ports1

FormatATX

Front panel audio connectorYes

GamingNu

HDMIDa

HDMI ports quantity1

Headphone outputs1

LAN controllerDragon RTL8125BG

Line-inYes

Maximum internal memory128 GB

Maximum number of SMP processors1

MB-FormatATX

MB-Socket1700

Memorie maxima128 GB

Memory channelsDual-channel

Memory slots typeDIMM

Model ChipsetZ790

Motherboard chipsetIntel Z790

Motherboard chipset familyIntel

Motherboard form factorATX

Numar sloturi memorie4

Number of M.2 (M) slots1

Number of memory slots4

Number of SATA III connectors4

Onboard-CPUNo

PCI0

PCI Express x1 (Gen 3.x) slots3

PCI Express x16 (Gen 4.x) slots1

PCI Express x16 (Gen 5.x) slots1

PCI-Ex13

PCI-Ex162

Processor manufacturerIntel

Processor socketLGA 1700

PS/2 ports quantity1

RAID levels0, 1, 5, 10

RAID supportYes

RAM-Slots4

RGB LED pin headerYes

RJ-45 LAN1

Serial-or-ParalelNo/No

Sloturi M.23

Soclu ProcesorSocket 1700

Supported memory typesDDR4-SDRAM

Supported storage drive interfacesM.2, SATA III

Supported storage drive typesHDD & SSD

ThunderboltNu

Thunderbolt headers1

Tip MemorieDDR4

Tip slot interfata graficaPCIe 5.0 x16

TPM connectorYes

Unbuffered memoryYes

USB 2.0 connectors1

USB 2.0 ports quantity1

USB 3.2 Gen 1 (3.1 Gen 1) connectors2

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity5

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0

USB 3.2 Gen 2 (3.1 Gen 2) connectors1

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity1

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity0

USB 3.2 Gen 2x2 Type-C ports quantity1

USB Type CDa

USB34-8

Video-ConnectionHDMI/DP

Wi-FINo

Width30.5 mm

Windows operating systems supportedWindows 10 x64, Windows 11 x64

WirelessNu

Specificații

Brand	ASROCK
Cod produs	NOD-Z790 PG LIGHTN/D4
Categorie	Componente
Garanție	Se confirmă la ofertare
Livrare	5–7 zile
Bluetooth	Nu
ATX Power connector (24-pin)	Yes
Audio Chip	Realtek ALC897
Audio output channels	7.1 channels
BIOS memory size	128 Mbit
BIOS type	UEFI AMI
Canale audio	7.1
Chipset audio integrat	Realtek
Compatible processor series	Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9
Component for	PC
CPU fan connector	Yes
Depth	24.4 mm
DVI-D ports quantity	0
ECC сompatibility	Non-ECC
Ethernet interface type	2.5 Gigabit Ethernet
Ethernet LAN	Yes
Ethernet LAN (RJ-45) ports	1
Format	ATX
Front panel audio connector	Yes
Gaming	Nu
HDMI	Da
HDMI ports quantity	1
Headphone outputs	1
LAN controller	Dragon RTL8125BG
Line-in	Yes
Maximum internal memory	128 GB
Maximum number of SMP processors	1
MB-Format	ATX
MB-Socket	1700
Memorie maxima	128 GB
Memory channels	Dual-channel
Memory slots type	DIMM
Model Chipset	Z790
Motherboard chipset	Intel Z790
Motherboard chipset family	Intel
Motherboard form factor	ATX
Numar sloturi memorie	4
Number of M.2 (M) slots	1
Number of memory slots	4
Number of SATA III connectors	4
Onboard-CPU	No
PCI	0
PCI Express x1 (Gen 3.x) slots	3
PCI Express x16 (Gen 4.x) slots	1
PCI Express x16 (Gen 5.x) slots	1
PCI-Ex1	3
PCI-Ex16	2
Processor manufacturer	Intel
Processor socket	LGA 1700
PS/2 ports quantity	1
RAID levels	0, 1, 5, 10
RAID support	Yes
RAM-Slots	4
RGB LED pin header	Yes
RJ-45 LAN	1
Serial-or-Paralel	No/No
Sloturi M.2	3
Soclu Procesor	Socket 1700
Supported memory types	DDR4-SDRAM
Supported storage drive interfaces	M.2, SATA III
Supported storage drive types	HDD & SSD
Thunderbolt	Nu
Thunderbolt headers	1
Tip Memorie	DDR4
Tip slot interfata grafica	PCIe 5.0 x16
TPM connector	Yes
Unbuffered memory	Yes
USB 2.0 connectors	1
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	5
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) connectors	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
USB 3.2 Gen 2x2 Type-C ports quantity	1
USB Type C	Da
USB3	4-8
Video-Connection	HDMI/DP
Wi-FI	No
Width	30.5 mm
Windows operating systems supported	Windows 10 x64, Windows 11 x64
Wireless	Nu

Configurație

Placa de baza AsRock Z790 PG LIGHTNING LGA 1700, 4x DDR4, 1x HDMI 2.1, 1x eDP 1.4, 2x PCIe x16, 3x PCIe 3.0 x1, 3x M.2, 4x SATA, 2.5 Gigabit LAN, ATX

Ai nevoie de o configurație diferită? Echipa noastră o poate personaliza — Cere ofertă.

Prezentare detaliată

Placa de baza AsRock Z790 PG LIGHTNING LGA 1700, 4x DDR4, 1x HDMI 2.1, 1x eDP 1.4, 2x PCIe x16, 3x PCIe 3.0 x1, 3x M.2, 4x SATA, 2.5 Gigabit LAN, ATX

Bluetooth: NuATX Power connector (24-pin): YesAudio Chip: Realtek ALC897Audio output channels: 7.1 channelsBIOS memory size: 128 MbitBIOS type: UEFI AMI
