Prezentare detaliată

"Measurement: -Compliance with EN 50470-1/-3 standard -Connection type: 1P2W -Accuracy: Direct: Class B/ 1.0 -Constant: Direct:800imp/kWh Voltage: -Nominal Voltage(Un): 220V...240V -Operating Range: 0.9Un~1.1Un Current: Direct, 0.25-5(80)A Frequency: 50Hz or 60Hz LCD Display: -6 characters of 7 segment display -Digital size: 5.9mm×12.4mm LED Indication: Pluse Output Communications: -RS485,Modbus-RTU -Baud Rate:1200bps,2400bps,4800bps, 9600bps(default), 19200bps Measured Values: -Import/ExportkWh, kvarh -InstantaneouskW, kvar,kVA -Irms, Vrms, Frequency, Power factor,etc Environmental: -Operating Temperature : 25 °C to +55 °C -Storage Temperature : -35 °C to +70 °C -Relative Humidity: ≤ 95%RH(non-condensing) -Ingress Protection: IP20 Dimensions: -Dimensions:100mm×36mm×36mm ×65.5mm -Weight: 0.22 kg (Approx.)
