HPE Networking Instant On Secure Gateway 4-port Gigabit SG1004

• <h4>Lifecycle</h4><ul><li><b>Obsolete Date</b> 31-12-2099</li></ul><h4>Specifications</h4><ul><li><b>Ports</b> Total ports: 4 WAN Interface: 1x 10/100/1000-Base-T Ethernet WAN/LAN Configurable Interface: 1x 10/100/1000-Base-T Ethernet LAN Interfaces: 2x 10/100/1000-Base-T Ethernet</li><li><b>Mounting</b> Tabletop, wall</li><li><b>Certifications</b> Europe: EN 62368-1:2014 +A11:2017 EN 62368-1:2020 +A11:2020 US: UL 62368-1, 3rd Ed., Canada: CAN/CSA C22.2 No. 62368-1:19, 3rd Ed. Worldwide: IEC 62368-1:2014, 2nd Ed. IEC 62368-1: 2018, 3rd Ed. Taiwan: CNS-15598-1:2020 China: GB 4943.1:2022 Europe: EN 55032:2015 + A11:2020, Class B EN 61000-3-2:2019 EN 61000-3-3:2013 US: FCC 47 CFR part 15B: 2021, Class B Canada: ICES-003 Issue 7: 2020, Class B Worldwide: VCCI-CISPR 32, Class B CISPR 32: 2016, Class B AS/NZS CISPR 32: 2015, Class B CNS 15936: 2020, Class B CISPER 35: 2016 EN 55035:2017/A11:2020 IEC 61000-4-2 IEC 61000-4-3 IEC 61000-4-4 IEC 61000-4-5 IEC 61000-4-6 IEC 61000-4-8 IEC 61000-4-11 IEC/EN 61000-3-2 IEC/EN 61000-3-3 IEC/EN 63000:2018 KS C 9832</li><li><b>Warranty</b> 2-year, see the warranty duration guide.</li><li><b>Wi-Fi antenna</b> NA</li><li><b>Regulatory</b> Regulatory model number: RSVLC-2304</li><li><b>Weight</b> 2.3 lb</li><li><b>Product dimensions (metric)</b> 4.3 x 16.5 x 19.1 cm</li><li><b>Product dimensions (imperial)</b> 1.7 x 6.5 x 7.5 in</li><li><b>Weight</b> 1.0 kg</li></ul><h4>Quickspecs</h4><ul><li>QuickSpecs (PDF)</li><li>QuickSpecs</li><li>QuickSpecs</li><li>QuickSpecs (HTML)</li></ul><h4>Overview</h4><p>The HPE Networking Instant On Secure Gateway is a powerful, cloud-managed security solution designed for small and growing businesses. It delivers enterprise-grade security—firewall, IDS/IPS, VPN, PoE, and WAN resiliency—without hidden fees or licenses. Managed through a single platform, it offers domain blocking, deep packet inspection, and 24x7 network monitoring to protect against cyberthreats. Designed with ease of use in mind, it enables minimum-touch deployment and automated configuration, making network setup and management accessible even for non-technical users. Ideal for securing customer data, transactions, and multi-site connectivity, this gateway provides easy, reliable control tailored to SMB needs, combining simplicity with top-tier protection.</p><h4>What's new</h4><ul><li>Cloud-based management: Seamless remote monitoring and management controls through centralized Instant On Cloud Portal/app; automated firmware updates delivered through the cloud.</li><li>Secure the LAN: Implementation of Zero Trust model architecture and enhanced hardware-accelerated firewall features keep your business safe.</li><li>WAN redundancy and load balancing: Automatically selects the most optimal WAN connection when multiple ISP connections are detected for uninterrupted internet access.</li><li>Enhanced user experience: Improved and more intuitive design for simplified navigation and user experience.</li><li>PoE+ support (SG2505P): Up to 60W of Power over Ethernet (PoE) budget for simplified device deployment.</li><li>Multi-gigabit WAN support (SG2505P): New multi-gigabit WAN ports for faster and more reliable connectivity.</li></ul><h4>Features</h4><p>Great for small and medium businesses with ISP throughputs faster than a gigabit, utilizes the 2.5 G ports on the SG2505P for maximum throughput.</p><p>A PoE budget of 60W makes the SG2505P a smart choice for deploying a compact and easy-to-manage network by powering Instant On access points without an additional switch.</p><b>Active Threat Monitoring with Intrusion Detection and Prevention (IDS/IPS)</b><p>IDS and IPS monitor network traffic for suspicious activities. IDS detects and alerts administrators about potential security breaches, while IPS actively blocks or prevents threats in real-time.</p><p>Together, IDS and IPS enhance network security by identifying and responding to potential intrusions.</p><b>Keep the Network Safe with a Stateful Firewall</b><p>This monitors and controls network traffic based on policies, creating a barrier between trusted internal networks and untrusted external networks to prevent unauthorized access and cyber threats.</p><p>Default settings block external traffic from accessing the LAN. policies can allow or block traffic, enable port-forwarding, and client access.</p><b>Keep the Business Online with WAN Resiliency</b><p>This feature enables continuous connectivity during network disruptions using multiple ISP connections.</p><p>The secure gateway detects issues (link degradation or failure) and reroutes traffic to the best available ISP uplink, reducing downtime and service interruptions.</p><b>Multi-Gigabit and PoE Ports (SG2505P)</b><h4>Documents</h4><ul><li>HPE Networking Instant On Secure Gateway QuickSpecs</li></ul>
