HPE Networking Instant On Access Point Bundle with PSU (WW) AP25

• <h4>Lifecycle</h4><ul><li><b>Obsolete Date</b> 31-12-2099</li></ul><h4>Specifications</h4><ul><li><b>Input voltage</b> PoE: 802.3at (class 4) DC power (12V) Note: Power sources are sold separately unless you purchase the bundle SKU</li><li><b>Radio coverage</b> Dual-radio 802.11ax 4x4 5 GHz MU-MIMO 2x2 2.4 GHz MU-MIMO</li><li><b>Certifications</b> Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3</li><li><b>Ports</b> 1x 2.5 GbE Base-T uplink port DC power connector Bluetooth Low Energy (BLE) LED status indicators Reset/LED control button Kensington security slot</li><li><b>Connectivity, standard</b> Ultra-fast 802.11ax, 4x4:4</li><li><b>Mounting</b> Ceiling/Wall mount clip</li><li><b>Warranty</b> Instant On 2-year warranty includes 24X7 phone support for the first 90 days and chat support for the entire warranty period. Community support is available for the life of the product.</li><li><b>Wi-Fi antenna</b> Antennas: Dual omni-directional 4x4 MU-MIMO Antenna Gain: 3.7 dBi in 2.4GHz 4.5 dBi in 5 GHz Maximum transmit power: 5 GHz band: +24 dBm (+18 dBm per chain, 6 dB MIMO gain) 2.4 GHz band: +21 dBm (+18 dBm per chain, 3 dB MIMO gain)</li><li><b>Power consumption</b> Max power consumption (worst-case): 20.1W (PoE), 15.9W (DC)</li></ul><h4>Quickspecs</h4><ul><li>QuickSpecs (HTML)</li><li>QuickSpecs</li><li>QuickSpecs (PDF)</li><li>QuickSpecs</li></ul><h4>Overview</h4><p>Wi-Fi Certified 6TM HPE Networking Instant On Access Points AP25 delivers faster Wi-Fi speeds, greater capacity, and reduced latency between access points and devices for a superior Wi-Fi experience. With the AP25, you can upgrade your Wi-Fi network to boost performance across devices now, while preparing it for more mobile and IoT devices in the future. Features include Orthogonal frequency-division multiple access (OFDMA), multi-user MIMO, and target wake time (TWT). With up to 4 spatial streams (4SS) and 160 MHz channel bandwidth (HE160), the Instant On AP25 provides outstanding wireless capabilities for businesses looking to future-proof their networks.</p><h4>What's new</h4><ul><li>Wi-Fi 6 certification supports all mandatory 802.11ax features that include MU-MIMO, OFDMA, TWT, and more</li><li>Provides a high performance Dual Radio 802.11ax AP with 4 spatial streams (4X4) for higher capacity and coverage</li><li>This series features maximum data rates of 4.8 Gbps in the 5 GHz band and 574 Mbps in the 2.4 GHz band (for an aggregate peak data rate of 5.3 Gbps)</li><li>Instant On mobile app and/or cloud-based web portal allows for easy network management onsite or remotely</li><li>Includes 2.5 Gigabit Ethernet uplink port and 160 MHz channel bandwidth for increased wireless throughput</li><li>Support for WPA2/WPA3 protected employee and guest login with Enhanced Open for per user guest access</li></ul><h4>Features</h4><p>HPE Networking Instant On Access Points AP25 comes with integrated Wi-Fi Alliance security standard WPA2/WPA3 and Enhanced Open support for protected wireless access.</p><b>Incredible Efficiency with Wi-Fi 6</b><p>The HPE Networking Instant On Access Points AP25 supports the Wi-Fi 6 standard, including features such as orthogonal frequency-division multiple access (OFDMA) and Multi-User MIMO (MU-MIMO), and Target Wait Time (TWT).</p><b>Safeguard Sensitive Data with WPA2/WPA3 and Enhanced Open</b><p>160 MHz channel bandwidth delivers increased mesh throughput and Wi-Fi speed ideal for high-def video streaming and virtual reality devices.</p><p>2.5 Gigabit Ethernet uplink port enhances wireless connectivity.</p><p>HPE Networking Instant On Access Points AP25 support features Target Wake Time (TWT) that helps establish a schedule when clients need to communicate with an access point improving efficiency for longer battery life.</p><p>HPE Networking Instant On Access Points AP25 features integrated router, gateway, and firewall functionality.</p><p>HPE Networking Instant On Access Points AP25 supports Two-Factor Authentication (2FA) for additional layer of authentication, preventing attackers from remotely accessing your networks.</p><p>The HPE Networking Instant On Access Points AP25 are 100% backward compatible, allowing businesses to support multiple clients (Wi-Fi 6) and legacy (11a/b/g/n/ac) at the same time.</p><p>Performance benefits of Orthogonal Frequency Division Multiple Access (OFDMA) are improved, meaning increased network performance and network capacity.</p><p>High-performance HPE Networking Instant On Access Points AP25 brings powerful 4 spatial streams for superior Wi-Fi coverage.</p><p>The HPE Networking Instant On Access Points AP25 delivers higher capacity, efficiency, and performance to small and growing businesses with device-dense environments.</p><p>Create up to eight different SSIDs under one network name to keep your data safe, whether surfing the web or checking HR data.</p><b>Higher Performance and Superior Coverage</b><h4>Compatible products</h4><ul><li>HPE Networking Instant On 30W 802.3at PoE Midspan Injector</li><li>HPE Networking Instant On 12V/18W Power Adaptor US EU</li><li>HPE Networking Instant On AP25 Flush Mount Sleeve</li><li>HPE Aruba Networking AP-MNT-W4 White Low Profile Basic AP Flat Surface Mount Kit</li><li>ARUBA INSTANT ON 12V POWER ADAPTER RW</li><li>HPE Aruba Networking Foundational Care 3Y NBD Exch Instant ON Access Point SVC</li></ul><h4>Documents</h4><ul><li>Interconnected retail on a massive scale – The Home Depot</li><li>Interconnected retail on a massive scale – The Home Depot</li><li>HPE Networking Instant On Wi-Fi 6 Access Points QuickSpecs</li></ul>
